Round manhole covers

Round manhole cover - EIXO E DOBRADIÇA
12.100

Datasheet
Certificates
CAD / 3D Drawing

Features:

  • Certified product according to EN 124 (Class D400)
  • With hinge and conical closing system
  • Automatic closing system
  • Safety 90º blocking system
  • Cover with 7 guides for centrally positioned and stability on its frame
  • Hinge with self-cleaning system
  • Inscriptions and logos in high relief
  • Cover and frame: ductile cast iron EN-GJS-500-7 (GGG50)
  • Elastic seating for noise prevent: PVC flexible
  • Coating: Non-toxic water based black paint

Code Description CAD Drawing PDF Drawing Quantity
24B1CI3EAFBZZZZZ00EE 600 - C250 075 Alt.
24B1CI3EAFBZZZZZ00IE 600 - C250 075 Alt. + [A-R]
24B1CI3EAFBZZZZZ00GE 600 - C250 075 Alt. + [F-S]
24B1CI3EAFBZZZZZ00JE 600 - C250 075 Alt. + [F-S] + [A-R]
24B1CI4EAFBZZZZZ00EE 600 - D400 075 Alt.
24B1CI4EAFBZZZZZ00IE 600 - D400 075 Alt. + [A-R]
24B1CI4EAFBZZZZZ00HE 600 - D400 075 Alt. + [F-S-I]
24B1CI4EAFBZZZZZ00KE 600 - D400 075 Alt. + [F-S-I]+[A-R]
24B1CI4EAFBZZZZZ00GE 600 - D400 075 Alt. + [F-S]
24B1CI4EAFBZZZZZ00JE 600 - D400 075 Alt. + [F-S]+[A-R]
24B1CI4EAIBZZZZZ00EE 600 - D400 100 Alt.
24B1CI4IAIBZZZZZ00EE 600 - D400 100 Alt. - Modelo Tráfego Intenso/Series Intense Traffic
24B1CI4EAIBZZZZZ00IE 600 - D400 100 Alt. + [A-R]
24B1CI4IAIBZZZZZ00IE 600 - D400 100 Alt. + [A-R] - Modelo Tráfego Intenso/Series Intense Traffic
24B1CI4EAIBZZZZZ00HE 600 - D400 100 Alt. + [F-S-I]
24B1CI4EAIBZZZZZ00KE 600 - D400 100 Alt. + [F-S-I]+[A-R]
24B1CI4EAIBZZZZZ00GE 600 - D400 100 Alt. + [F-S]
24B1CI4EAIBZZZZZ00JE 600 - D400 100 Alt. + [F-S] + [A-R]
24B1CI4EAIEZZAPT20JE 600 - D400 100 Alt. + [F-S] + [A-R] - Modelo Águas do Porto
24B1CI4EAIEZZAPT20GE 600 - D400 100 Alt. + [F-S] - Modelo Águas do Porto
24B1CX4EAIBZZZZZ00EE 750 - D400 100 Alt.
24B1CX4EAIBZZZZZ00IE 750 - D400 100 Alt. + [A-R]
