Casquilho para tubo PE
15.400

Ficha Técnica
Desenho CAD / 3D

Características:

  • Casquilho em aço inox AISI 304
  • Para reforço interior das tubagens de PE
  • *Pedidos mínimos de 10 unidades por cada artigo

Código Descrição Desenho CAD Quantidade
10801422 DN 110 x 10.0/9.5 x 175 mm
10801424 DN 110 x 15.1 x 175 mm
10801420 DN 110 x 6.6/6.3 x 175 mm
10801430 DN 125 x 11.4 x 175 mm
10801426 DN 125 x 3.7/3.1 x 175 mm
10801428 DN 125 x 7.4/7.1 x 175 mm
10801434 DN 140 x 12.8 x 175 mm
10801432 DN 140 x 8 x 175 mm
10801440 DN 160 x 14.6 x 200 mm
10801436 DN 160 x 4.5/3.9 x 200 mm
10801438 DN 160 x 9.5/9.1 x 200 mm
10801442 DN 180 x 10.7/10.2 x 200 mm
10801444 DN 180 x 16.4 x 200 mm
10801446 DN 200 x 11.9/11.4 x 200 mm
10801448 DN 200 x 18.2 x 200 mm
10801452 DN 225 x 13.4/12.8 x 225 mm
10801454 DN 225 x 20.2 x 225 mm
10801450 DN 225 x 6.3/5.5 x 225 mm
10801456 DN 250 x 14.8/14.2 x 225 mm
10801458 DN 250 x 22.7 x 225 mm
10801462 DN 280 x 16.6/15.9 x 225 mm
10801464 DN 280 x 25.4 x 225 mm
10801460 DN 280 x 8.7 x 225 mm
10801468 DN 315 x 12.4 x 225 mm
10801470 DN 315 x 17.9 x 225 mm
10801471 DN 315 x 17.9 x 225 mm
10801472 DN 315 x 18.7 x 225 mm
10801466 DN 315 x 9.2 x 225 mm
10801474 DN 355 x 20.1 x 225 mm
10801476 DN 355 x 32.3 x 225 mm
10801478 DN 355 x 35 x 225 mm
10801480 DN 355 x 40 x 225 mm
10801482 DN 400 x 11.7 x 225 mm
10801484 DN 400 x 15.4 x 225 mm
10801486 DN 400 x 20.5 x 225 mm
10801488 DN 400 x 22.7/23.7 x 225 mm
10801490 DN 500 x 21.5 x 225 mm
10801492 DN 500 x 28.3 x 225 mm
10801494 DN 500 x 30 x 225 mm
10801400 DN 63 x 3.6 x 175 mm
10801402 DN 63 x 5.8/5.1 x 175 mm
10801404 DN 63 x 8.6 x 175 mm
10801410 DN 75 x 10.3 x 175 mm
10801406 DN 75 x 4.3 x 175 mm
10801408 DN 75 x 6.8/6.5 x 175 mm
10801418 DN 90 x 12.3 x 175 mm
10801412 DN 90 x 2.7/2.2 x 175 mm
10801414 DN 90 x 5.4/5.1 x 175 mm
10801416 DN 90 x 8.2/7.8 x 225 mm
